9 APPENDIX F – TERMINAL SPECIFICATIONS
9.1 IPmodem (indoor unit)
Performance
 IP data Throughput : up-to 7 Mbps IP forward
up-to 626 kbps IP return
 Max. download rate multicast : 16 Mbps total multicast IP rate
 Max. concurrent multicasts : 10
 Simultaneous TCP sessions : 100
Interface

RF in (from iLNB)
 Frequency : 950 – 2150 MHz
 Connector : F (female) – 75 Ohm
 RF out (to iLNB)
 Frequency : 2750 – 2900 MHz
 Connector : F (female) – 75 Ohm
Power Supply

Power supply : 15 V (external adaptor)
 Mains adaptor input : 100-240 V AC – 0.9A
 Mains power consumption : 30 W maximum
Environment

Operational : 0 to 40 °C
 Storage : -10 to 60 °C
 Humidity : 10 ~ 70% (non-condensing)
Dimensions

W190 x D180 x H53 mm (including RF connectors)
 Weight : 0.5 kg
9.2 Coaxial cable
Electrical
 Frequency range : 0.5 – 3.0 GHz
 Impedance : 75 +/- 3 Ohm
 Attenuation : < 18.0 dB @ 3000 MHz
 Return loss : > 18 dB up to 2150 MHz, > 15 dB up to 3000 MHz
 Structural return loss : up to 3 peaks of > 15 dB over 0.5 – 3.0 GHz band
