Modem Reference Manual for EL470 IP Satellite Modem
Config
In the configuration menu you can save and load up to 48 different operational
configurations in permanent memory. You can define a configuration as the group
of all device configuration parameters that can be set in the IP Satellite Modem.
Only global system parameters are not saved in a configuration since they are
written in permanent memory at the moment that they are set/changed. They are
parameters that are common to all configurations such as: Device mode, RMCP
version, Display contrast. Serial interface type, Device RMCP address, Serial
baudrate, Device IP address, Device IP mask, Default gateway and Ethernet
interface Alarm mode (normal, masked and forced). All other parameters are
configuration parameters that can differ in the different stored configurations.
The config tab is not displayed in the tree view of the Graphical
user interface (GUI). This function is located in the Function
controls window of the GUI under the tab config.
We refer to the explanation of the GUI in the user manual of this
device.
Special Command
SyConfigLoadFlash
Load Load
Location /Config
Description
Command used to load a configuration from permanent memory. Up to 48
different configurations can be loaded, however only valid configurations
that have been previously saved by the operator can be loaded. The
default boot configuration must always be stored in configuration 0 since
this is the one that is loaded when the device (re)-boots.
The top row on the LCD display indicates the last loaded configuration by
the name given by the operator to the configuration number.
Remark specific to modulators: Only the default boot configuration can
store the status of L-band (IF) transmit since it is required that
transmission resumes if there was an (accidental) power outage.
Remember that in that case the default configuration 0 is loaded. The
other configurations will save the transmit status as disabled and the
operator will have to verify all parameters before enabling transmit to go
on-air.
RMCP
Command
LCF Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyConfigLoadFlash
OID 1.3.6.1.4.1.5835.3.1.1.1.3.1.1
Get Command Arguments Set Command Arguments
Command(s) / Variable(s) Page Command(s) / Variable(s) Page
none none SyConfigNum 230
Get Reply Values Set Reply Values
Command(s) / Variable(s) Page Command(s) / Variable(s) Page
SyLoadConfNum 231 SyConfigStatus 230
version 3.1
