Newtec EL470 - Structured Elements with Individual Access

Modem Reference Manual for EL470 IP Satellite Modem
Structured Elements with Individual Access
Command
DmMeasEbNoSat
Eb/No level clipping
info
Eb/No lvl clipping
Used as
variable of
Command(s)
DmMeasEbNoStruct
Page
158
Description
Readout of the Eb/No level clipping information. When reading saturated
values for the Eb/No estimation, the clipping information will identify the
direction of saturation or return equal if the value is within range.
RMCP
Command
Rse Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmMeasEbNoSat
OID 1.3.6.1.4.1.5835.3.1.13.1.37.1.1
Values Factory Default
equal
Enumeration Value
>
<
0
1
2
Command
DmMeasEbNo
Eb/No estimation Eb/No estimation
Used as
variable of
Command(s)
DmMeasEbNoStruct
Page
158
Description
Readout of the Eb/No estimation in dB of the received signal.
RMCP
Command
Rle Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmMeasEbNo
OID 1.3.6.1.4.1.5835.3.1.13.1.19.1.1
Values GUI Unit
dB
Cmd Unit Factory Default (CU)
dB 9.83
Expert Range (CU)
0 .. 25
Command
DmModCodStatModCod
FEC-rate and
modulation
FEC-rate and mod.
Used as
variable of
Command(s)
DmModCodStatStruct
Page
162
Description
Readout of the actual value of the forward error correction coding and
modulation.
RMCP
Command
Msx Access Normal user : R
Expert user : R
version 3.1
168
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
