Modem Reference Manual for EL470 IP Satellite Modem
Structured Command
DmMeasAGCCoStruct
Input level Input level
Variables
DmMeasAGCCoSat
DmMeasAGCCo
Page
174
175
Structured Command
DmMeasEbNoStruct
Eb/No estimation Eb/No estimation
Location /Modem/Monitor/Demodulation
Description
Readout of the DVB-S demodulator channel Eb/No estimation. This Eb/No
estimation is based on a symbol noise estimation. This estimation is
calculated on all symbols, but is not very accurate (+/- 1dB). This variable
is the concatenation of DmMeasEbNoSat and DmMeasEbNo.
RMCP
Command
RSe Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmMeasEbNoStruct
OID 1.3.6.1.4.1.5835.3.1.13.1.38.1.1
Variables
DmMeasEbNoSat
DmMeasEbNo
Page
168
168
Command
DmMPegCrcErrs
MPEG CRC errors MPEG CRC errors
Location /Modem/Monitor/Demodulation
Description
Readout of the total counted MPEG errors. These accumulated counter
can be reset by using the command for resetting counters.
RMCP
Command
McE Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmMPegCrcErrs
OID 1.3.6.1.4.1.5835.3.1.13.1.47.1.1
Values GUI Unit Cmd Unit Factory Default (CU)
0
Expert Range (CU)
0 .. 4294967295
Command
DmMeasCarOff
Carrier frequency
offset
Carrier freq. offset
Location /Modem/Monitor/Demodulation
Description
Readout of the measured carrier frequency offset in Hz of the received
carrier frequency against the selected receive frequency.
RMCP
Command
Rfd Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
version 3.1
