APPENDIX A: ACTION KEYS
The idea behind Action Keys is that you as system integrator can define a group of
frequently executed operations to configure the device. Use the numerical keypad
as a selection panel. When you press a certain number, a string appears that
clearly describes the commands that will be executed. You can then press OK to
execute the command(s).
Contrary to loading complete device configurations by using the load and save
configurations option, you can define group of commands (1-20) that have to be
executed when you execute a specific Action Key.
The action keys are not displayed in the tree view of the Graphical
user interface (GUI). This function is in the Function controls
window of the GUI under the tab Macro.
We refer to the explanation of the GUI in the user manual of this
device.
Definition of the Action Keys
 EL470>> Actionkeys
Special Command
SyActKeyActivate
Action keys
Location Modulator/Actionkeys
Description
This command represents a key-press when in the ActionKey menu. An
expert user can program the actions taken when such a key is pressed.
RMCP
Command
AKa Access Normal user : W
Expert user : W
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyActKeyActivate
OID 1.3.6.1.4.1.5835.3.1.1.1.47.1.1
Get Command Arguments Set Command Arguments
Command(s) / Variable(s) Page Command(s) / Variable(s) Page
NA NA
SyActionKeyId
229
Get Reply Values Set Reply Values
Command(s) / Variable(s) Page Command(s) / Variable(s) Page
NA NA
SyActionKeyReply
229
