Operation
Reference Manual for EL470 IP Satellite Modem
2 OPERATION
Overview
In this overview you see the menu structure of variables in the EL470. This is also
the menu of the Graphical User Interface (GUI). The main categories in the EL470
device are shown in Table 1 .
EL470 Page
User 11
Unit 12
IP Satellite Modem 44
Alarm 246
Config 166
Table 1 - High level structure of device parameters
The following tables show the structure details of the EL470 menu.
For a list of all the commands and their page reference, refer to the list of
Commands at the end of this document.
EL470 IP Satellite Modem Page
Unit 12
Setup 12
Serial port settings 14
Ethernet settings 15
Display settings 17
SNMP settings 18
Web Interface 19
Control 20
AES 29
Monitor 31
Architecture 34
Diagnostics 43
version 3.1
8
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
