Modem Reference Manual for EL470 IP Satellite Modem
Command
MdProcMode
Processing mode Processing mode
• Eth(ntS2BBF) -> Air(S2BBF), applicable for DVB-S2. Transparent
DVB-S2 Baseband frames received from a Newtec
encapsulator forwarded from an Ethernet input to the
modulator board and from demodulator back to Ethernet
output.
RMCP
Command
DPm Access Normal user : RW
Expert user : RW
SNMP Table ntcDevsMod01ModemEntry
Command ntcDevsMod01MdProcMode
OID 1.3.6.1.4.1.5835.3.1.18.1.7.1.1
Values Factory Default
tsmode
Enumeration Value
Eth(IP)<->Air(TS)
Eth(IP)<->Air(XPE)
Eth(TSoIP)<->Air(TS)
Eth(S2BBF)<->Air(S2BBF)
Eth(ntS2BBF)->Air(S2BBF)
0
1
4
8
10
/Modem/Control/Interfaces
/Modem/Control/Interfaces/Ethernet
Command
IfEthMtu
Ethernet MTU Ethernet MTU
Location /Modem/Control/Interfaces/Ethernet
Description
Configuration of the Ethernet payload size. This number defines the
maximum Ethernet payload size which is usually 1500 bytes. It does not
include the Ethernet header, the Ethernet frame check sequence
(=CRC32) or the VLAN extension of 4 bytes.
RMCP
Command
mtu Access Normal user : no
access
Expert user : RW
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfEthMtu
OID 1.3.6.1.4.1.5835.3.1.4.1.244.1.1
Values GUI Unit
NA
Cmd Unit Factory Default (CU)
NA 1500
Expert Range (CU)
1500 .. 1600
version 3.1
45
