Unit Menu
Reference Manual for EL470 IP Satellite Modem
/Unit/Architecture
Retrieving Architectural Information
The architecture parameters are a special case in commands. In this section you
can find all the commands to retrieve architecture information from the device.
First, there is the architecture information on device level. They can be retrieved via
the menu tree:EL470 >> Unit >> Architecture >> General. On device level, the
SNMP commands can be used, or RMCP using the command and the address
111.
There is also the architecture information on board level within the device.
WARNING: SNMP can not be used to retrieve architecture information on board
level. The RMCP commands that are used to retrieve board level information are
the same as the commands used on device level. On board level, the used
addresses used is 100, and the subaddress depends on the board: These are the
subadresses for the several boards:
• M&C module: 48 (in RMCPLoader -1:1:0 is used)
• Interface: 100 (in RMCPLoader -1:1:d is used)
• Modulation: 116 (in RMCPLoader -1:1:t) is used
The applicability of the commands are shown in following table:
Unit/Architecture/general
Nr Command Name Page
1 Device Serial Number 37
2 Device Type 41
3 Product Number 42
4 Bucket version 37
5 OS version 38
6 RAM Disk version 38
7 PPC boot version 38
8 SNMP Daemon version 39
version 3.1
34
