Unit Menu Reference Manual for EL470 IP Satellite Modem
Unit/Diagnostics
Diagnostics is not displayed in the tree view of the Graphical user
interface (GUI). This function is located in the Function controls
window of the GUI under the tab Reset Device.
We refer to the explanation of the GUI in the user manual of this
device.
Command
SyTSRapport
Generate diagnostics
report
Diagnostics report
Location /Unit/Diagnostics
Description
Command to generate a diagnostics report. This command is also
triggered when a diagnostics report is requested through the web
interface.
There are two possible reports:
• A basic diagnostics report: To be used by customers to request all
configuration settings and alarms.
• A full diagnostics report: To be used by Newtec engineering as a
debugging tool to investigate specific problems detected by the basic
diagnostics report.
RMCP
Command
GTS Access Normal user : no access
Expert user : W
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyTSRapport
OID 1.3.6.1.4.1.5835.3.1.1.1.65.1.1
Values Factory Default
basic
Enumeration Value
Basic
Full
0
1
Special Command
AlSelfTestBrd
Board selftest result Board selftest resul
Location /Unit/Diagnostics
Description
Readout of the the concatenated string of the board self test results.
RMCP
Command
DSt
array : [1 .. 16]
Access Normal user : no access
Expert user : RW
Get Command Arguments Set Command Arguments
Command(s) / Variable(s) Page Command(s) / Variable(s) Page
none none none none
Get Reply Values Set Reply Values
Command(s) / Variable(s) Page Command(s) / Variable(s) Page
AlSelfTestString 193 AlSelfTestString 193
version 3.1
