Modem Reference Manual for EL470 IP Satellite Modem
Command
DmModCodStatModCod
FEC-rate and
modulation
FEC-rate and mod.
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmModCodStatModCod
OID 1.3.6.1.4.1.5835.3.1.13.1.69.1.1
Values Factory
Default
QPSK-3/4
Enumeration Value
Dummy PLFRAMES
QPSK modulation -- no FEC (Skyplex only)
QPSK modulation -- rate 1/2 * 188/204
QPSK modulation -- rate 2/3 * 188/204
QPSK modulation -- rate 3/4 * 188/204
QPSK modulation -- rate 5/6 * 188/204
QPSK modulation -- rate 6/7 * 188/204
QPSK modulation -- rate 7/8 * 188/204
QPSK-1/4
QPSK-1/3
QPSK-2/5
QPSK-3/5
QPSK-4/5
QPSK-8/9
QPSK-9/10
16APSK-2/3
16APSK-3/4
16APSK-4/5
16APSK-5/6
16APSK-8/9
16APSK-9/10
32APSK-3/4
32APSK-4/5
32APSK-5/6
32APSK-8/9
32APSK-9/10
16QAM modulation -- no FEC (Skyplex only)
16 QAM modulation -- rate 1/2 * 188/204
16 QAM modulation -- rate 2/3 * 188/204
16 QAM modulation -- rate 3/4 * 188/204
16 QAM modulation -- rate 5/6 * 188/204
16 QAM modulation -- rate 6/7 * 188/204
16 QAM modulation -- rate 7/8 * 188/204
16 QAM modulation -- rate 8/9 * 188/204
8PSK modulation -- no FEC (Skyplex only)
8PSK modulation -- rate 3/5 * 188/204
8PSK modulation -- rate 2/3 * 188/204
8PSK modulation -- rate 3/4 * 188/204
8PSK modulation -- rate 5/6 * 188/204
8PSK modulation -- rate 6/7 * 188/204
8PSK modulation -- rate 7/8 * 188/204
8PSK modulation -- rate 8/9 * 188/204
8PSK-9/10
0
10
11
12
13
15
16
17
21
22
23
24
25
26
27
42
43
44
45
48
49
53
54
55
58
59
60
61
62
63
65
66
67
68
80
81
82
83
85
86
87
88
89
version 3.1
169
