Modem Reference Manual for EL470 IP Satellite Modem
Command
DmModCodStatFrameType
Frame type Frame type
Used as
variable of
Command(s)
DmModCodStatStruct
Page
162
Description
Readout of the DVB-S2 forward error correction (FEC) frame type
detected after reception:
• Normal: FEC-frames of 64800 bits or 8100 bytes.
• Short: FEC-frames of 16200 bits or 2025 bytes.
RMCP
Command
Msl Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmModCodStatFrameType
OID 1.3.6.1.4.1.5835.3.1.13.1.68.1.1
Values Factory Default
short
Enumeration Value
Short
Normal
0
1
Command
DmModCodStatPilots
Pilots Pilots
Used as
variable of
Command(s)
DmModCodStatStruct
Page
162
Description
Readout of the actual value of the DVB-S2 physical layer pilot detection.
RMCP
Command
Msp Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmModCodStatPilots
OID 1.3.6.1.4.1.5835.3.1.13.1.70.1.1
Values Factory Default
off
Enumeration Value
Off
On
0
1
Command
DmModCodStatFrameCnt
BB frame count BB frame count
Used as
variable of
Command(s)
DmModCodStatStruct
Page
162
Description
Readout of the number of decoded baseband frames.
RMCP
Command
Msf Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmModCodStatFrameCnt
OID 1.3.6.1.4.1.5835.3.1.13.1.67.1.1
version 3.1
170
