Modem Reference Manual for EL470 IP Satellite Modem
Command
DmFECDemodStat
Actual FEC-rate and
modulation
Actual FEC-rate and
QPSK-3/5
QPSK-4/5
QPSK-8/9
QPSK-9/10
16APSK-2/3
16APSK-3/4
16APSK-4/5
16APSK-5/6
16APSK-8/9
16APSK-9/10
32APSK-3/4
32APSK-4/5
32APSK-5/6
32APSK-8/9
32APSK-9/10
16QAM modulation -- no FEC (Skyplex only)
16 QAM modulation -- rate 1/2 * 188/204
16 QAM modulation -- rate 2/3 * 188/204
16 QAM modulation -- rate 3/4 * 188/204
16 QAM modulation -- rate 5/6 * 188/204
16 QAM modulation -- rate 6/7 * 188/204
16 QAM modulation -- rate 7/8 * 188/204
16 QAM modulation -- rate 8/9 * 188/204
8PSK modulation -- no FEC (Skyplex only)
8PSK modulation -- rate 3/5 * 188/204
8PSK modulation -- rate 2/3 * 188/204
8PSK modulation -- rate 3/4 * 188/204
8PSK modulation -- rate 5/6 * 188/204
8PSK modulation -- rate 6/7 * 188/204
8PSK modulation -- rate 7/8 * 188/204
8PSK modulation -- rate 8/9 * 188/204
8PSK-9/10
24
25
26
27
42
43
44
45
48
49
53
54
55
58
59
60
61
62
63
65
66
67
68
80
81
82
83
85
86
87
88
89
/Modem/Monitor/Demodulation/ModCodStats
/Modem/Monitor/Demodulation/ModCodStats/Demodulator S2 statistics
Structured Command
DmModCodStatStruct
Demodulator S2
statistics
Demodulator S2 stati
Location /Modem/Monitor/Demodulation/ModCodStats/Demodulator S2 statistics
Description
Readout of the modulation and coding statistics table.
RMCP
Command
Mss
array : [1 .. 16]
Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorExtEntry
Command ntcDevsMod01DmModCodStatStruct
OID 1.3.6.1.4.1.5835.3.1.13000.1.4.1.1.[1 .. 16]
Variables
DmModCodStatModCod
DmModCodStatFrameType
Page
168
170
version 3.1
