Modem Reference Manual for EL470 IP Satellite Modem
Structured Command
DmEstLinMarStruct
Link Margin Estimate Link Margin Estimate
OID 1.3.6.1.4.1.5835.3.1.13.1.75.1.1
Variables
DmEstLinMarSat
DmEstLinMar
Page
190
190
Command
DmFrameTypeStat
FEC-frame type detect Frame type
Location /Modem/Monitor/Demodulation
Description
Reads out of the detected DVB-S2 FEC-frame type.
DVB-S2 defines two FEC-frame types :
• Normal: FEC-frames of 64800 bits or 8100 bytes.
• Short: FEC-frames of 16200 bits or 2025 bytes.
RMCP
Command
Acf Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmFrameTypeStat
OID 1.3.6.1.4.1.5835.3.1.13.1.56.1.1
Values Factory Default
short
Enumeration Value
Short
Normal
0
1
Command
DmFECDemodStat
Actual FEC-rate and
modulation
Actual FEC-rate and
Location /Modem/Monitor/Demodulation
Description
Readout of the actual value of the forward error correction coding &
modulation.
RMCP
Command
Rmx Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01DemodulatorEntry
Command ntcDevsMod01DmFECDemodStat
OID 1.3.6.1.4.1.5835.3.1.13.1.12.1.1
Values Factory
Default
QPSK-3/4
Enumeration Value
Dummy PLFRAMES
QPSK modulation -- no FEC (Skyplex only)
QPSK modulation -- rate 1/2 * 188/204
QPSK modulation -- rate 2/3 * 188/204
QPSK modulation -- rate 3/4 * 188/204
QPSK modulation -- rate 5/6 * 188/204
QPSK modulation -- rate 6/7 * 188/204
QPSK modulation -- rate 7/8 * 188/204
QPSK-1/4
QPSK-1/3
QPSK-2/5
0
10
11
12
13
15
16
17
21
22
23
version 3.1
161
SHAPING THE FUTURE OF SATELLITE COMMUNICATIONS
