Modem Reference Manual for EL470 IP Satellite Modem
Structured Command
IfQosStatsEntry
Eth RX QOS statistics Eth RX QOS statistic
Location /Modem/Monitor/Interfaces/Ethernet/ipencap/QOS Statistics
Description
Readout of the Ethernet RX quality of service statistics per quality of
service class.
RMCP
Command
eqs
array : [1 .. 4]
Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01InterfaceExtEntry
Command ntcDevsMod01IfQosStatsEntry
OID 1.3.6.1.4.1.5835.3.1.4000.1.18.1.1.[1 .. 4]
Variables
IfQosStatsPriority
IfQosStatsBytesDropped
Page
224
224
Command
IfAcmFwSigRxed
ACM fw sig rxed ACM fw sig rxed
Location /Modem/Monitor/Interfaces/Ethernet/ipencap/Signalling
Description
Number of ACM forward signalling packets received.
RMCP
Command
asf Access Normal user : no
access
Expert user : R
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfAcmFwSigRxed
OID 1.3.6.1.4.1.5835.3.1.4.1.266.1.1
Values GUI Unit
packets
Cmd Unit Factory Default (CU)
packets 0
Expert Range (CU)
0 .. 4294967295
Command
IfAcmFwSigFetched
ACM fw sig fetched ACM fw sig fetched
Location /Modem/Monitor/Interfaces/Ethernet/ipencap/Signalling
Description
Nbr of ACM fw signalling packets fetched.
RMCP
Command
asF Access Normal user : no
access
Expert user : R
SNMP Table ntcDevsMod01InterfaceEntry
Command ntcDevsMod01IfAcmFwSigFetched
OID 1.3.6.1.4.1.5835.3.1.4.1.265.1.1
Values GUI Unit
packets
Cmd Unit Factory Default (CU)
packets 0
Expert Range (CU)
0 .. 4294967295
version 3.1
144
