Unit Menu
Reference Manual for EL470 IP Satellite Modem
Command
SyRef10MTuning
10 MHz operator
frequency adjust
10 MHz oper. adjust
units units 0 -50 .. 50
Command
SyRef10MCalib
10 MHz ref. factory
default
10 MHz factory defau
Location /Unit/Control
Only applicable for modems equipped with a 10 MHz Reference Board.
Description
Readout of the internal 10MHz reference frequency calibration factory
default. This is the factory-calibrated tuning value for the internal 10 MHz
reference oscillator. This value is determined during factory calibration and
is hard-coded into the reference board. It can not be changed by the
operator.
This value will be used when SyRef10MCtrl is set to by factory.
Otherwise when set to by operator, the value entered in
SyRef10MTuning will be used to adjust the 10 MHz internal reference
frequency.
RMCP
Command
RFc Access Normal user : no
access
Expert user : R
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyRef10MCalib
OID 1.3.6.1.4.1.5835.3.1.1.1.42.0.1
Values GUI Unit
units
Cmd Unit Factory Default (CU)
units 0
Expert Range (CU)
-50 .. 50
Command
SyRef10MCtrl
10 MHz reference
calibration control
10 MHz cal. control
Location /Unit/Control
Only applicable for modems equipped with a 10 MHz Reference Board.
Description
Configuration of the internal 10MHz reference calibration control.
The internal 10MHz reference frequency can be controlled by either the
factory-calibrated value or the operator-controlled tuning value.
RMCP
Command
RFC Access Normal user : no access
Expert user : RW
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyRef10MCtrl
OID 1.3.6.1.4.1.5835.3.1.1.1.43.0.1
Values Factory Default
factory
Enumeration Value
By factory
By operator
0
1
version 3.1
25
