Newtec EL470 - Page 39

Unit Menu Reference Manual for EL470 IP Satellite Modem
Command
SyDevPowP12V
Device +12V power
supply
+12V power supply
Location /Unit/Monitor
Description
Readout of the +12volt power supply monitor. A power supply alarm is
triggered when this voltage is outside the range of +10.0 volt and +14.0
volt.
RMCP
Command
P12 Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyDevPowP12V
OID 1.3.6.1.4.1.5835.3.1.1.1.22.0.1
Values GUI Unit
V
Cmd Unit Factory Default (CU)
V 12
Expert Range (CU)
0 .. 50
Command
SyDevPowM12V
Device -12V power
supply
-12V power supply
Location /Unit/Monitor
Description
Readout of the -12 volt power supply monitor. A power supply alarm is
triggered when this voltage is outside the range of -10.0 volt and -14.0
volt.
RMCP
Command
M12 Access Normal user : R
Expert user : R
SNMP Table ntcDevsMod01SystemEntry
Command ntcDevsMod01SyDevPowM12V
OID 1.3.6.1.4.1.5835.3.1.1.1.21.0.1
Values GUI Unit
V
Cmd Unit Factory Default (CU)
V -12
Expert Range (CU)
-50 .. 0
Command
SyRef10MLevel
10 MHz reference input
level measurement
10 MHz input level
Location /Unit/Monitor
Only applicable for modems equipped with a 10 MHz Reference Board.
Description
Readout of the 10 MHz reference input level estimation as derived from
the monitored AGC level. For optimal operation (conform to the
specifications), the level should be within the range of 2.4 and 3.7 volt. A
level lower than 1 volt (lower than - 5 dBm) will trigger the reference clock
alarm. Following table shows the measured voltage and the corresponding
level in dBm:
a. 2.4 ± 0.5 volt => - 3 dBm.
b. 3.0 ± 0.5 volt => - 0 dBm.
c. 3.4 ± 0.5 volt => + 3 dBm.
d. 3.7 ± 0.5 volt => + 7 dBm.
e. 4.0 ± 0.5 volt => +10 dBm.
RMCP
Command
ril Access Normal user : no
access
version 3.1
