PPA5xx/15xx communications manual
2-99
Required Parameters MULTILOG Pattern
Command strings to sent, reference the above Multilog
pattern;
MULTIL,0 // clears Multilog
MULTIL,1,1,1 // set Frequency as parameter 1
MULTIL,2,1,2 // set Phase 1 Watts as parameter 2
MULTIL,3,2,2 // set Phase 2 Watts as parameter 3
MULTIL,4,3,2 // set Phase 3 Watts as parameter 4
MULTIL,5,1,50 // set Phase 1 RMS Voltage as parameter 5
MULTIL,6,2,50 // set Phase 2 RMS Voltage as parameter 6
MULTIL,7,3,50 // set Phase 3 RMS Voltage as parameter 7
Command
Index
Phase
Function
MULTIL,
1
1
1
MULTIL,
2
1
2
MULTIL,
3
2
2
MULTIL,
4
3
2
MULTIL,
5
1
50
MULTIL,
6
2
50
MULTIL,
7
3
50
Order
parameter
to be
returned
within
string
Phase
(channel)
of data
returned
Parameter
required
1
1
Frequency
2
1
Watts
Phase 1
3
2
Watts
Phase 2
4
3
Watts
Phase 3
5
1
RMS
Voltage
Phase 1
6
2
RMS
Voltage
Phase 1
7
3
RMS
Voltage
Phase 1
