Chapter 2: Jumpers and Connectors
NISE 3140, NISE 3140E, NISE 3140P2, NISE 3140P2E User Manual
External I/O Interface
Connector Pin Definitions
Status Indicators
Status LED Color
PWR Green
HDD Yellow
LNK1, LNK2 Green lighted: LAN ports linked
ACT1, ACT2 Yellow blinking: Data activity
PWR
HDD
USB Ports
Connector size: Dual USB port
Connector location: CN11
LNK1
ACT1
LNK2
ACT2
Pin Definition Pin Definition
1 VCC5 7 USB5+
2 USB4- 8 GND
3 USB4+ 22 GND
4 GND 23 GND
5 VCC5 26 GND
6 USB5- 27 GND
