Chapter 2: Jumpers and Connectors
NISE 3140, NISE 3140E, NISE 3140P2, NISE 3140P2E User Manual
Pin Definition Pin Definition
A43 PCI_PAR B43 VCC3
A44 PCI_AD15 B44 PCI_CBE#1
A45 VCC3 B45 PCI_AD14
A46 PCI_AD13 B46 GND
A47 PCI_AD11 B47 PCI_AD12
A48 GND B48 PCI_AD10
A49 PCI_AD9 B49 GND
A52 PCI_CBE#0 B52 PCI_AD8
A53 VCC3 B53 PCI_AD7
A54 PCI_AD6 B54 VCC3
A55 PCI_AD4 B55 PCI_AD5
A56 GND B56 PCI_AD3
A57 PCI_AD2 B57 GND
A58 PCI_AD0 B58 PCI_AD1
A59 VCC5 B59 VCC5
A60 PU1_REQ64# B60 PU1_ACK64#
A61 VCC5 B61 VCC5
A62 VCC5 B62 VCC5
PCIe x1 Slot
Connector size: PCIe x1
Connector location: CON2
Pin Definition Pin Definition
A1 PRSNT1# B1 +12V
A2 +12V B2 +12V
A3 +12V B3 +12V
A4 GND B4 GND
A5 NC B5 SMB_CLK
A6 NC B6 SMB_DATA
A7 NC B7 GND
A8 NC B8 VCC3
A9 VCC3 B9 NC
A10 VCC3 B10 3VSB
A11 PERST# B11 WAKE#
A12 GND B12 NC
A13 PCIE_CLK_P B13 GND
A14 PCIE_CLK_N B14 TXP3
A15 GND B15 TXN3
A16 RXP3 B16 GND
A17 RXN3 B17 NC
A18 GND B18 GND
