Chapter 2: Jumpers and Connectors
NISE 3140, NISE 3140E, NISE 3140P2, NISE 3140P2E User Manual
Power Push Button
Connector location: SW1
Pin Definition
1 GND
2 PWRBT
3 PWRBT
4 GND
A1 PWRLED
C1 PWRLED
MH1 NC
MH2 NC
External LED Pin Header
Connector size: 2x7 (2.54mm -M-180)
Connector location: J8
2
1
13 14
Pin Description Pin Description
1 LED_PWRN 2 LED_PWRP
3 HD_LEDN 4 LED_HDDP
5 LAN1_LINK# 6 LAN1_LINKP
7 LAN1_LED_ACT# 8 LAN1_ACTP
9 LAN2_LINK# 10 LAN2_LINKP
11 LAN2_LED_ACT# 12 LAN2_ACTP
13 NC 14 NC
