Chapter 2: Jumpers and Connectors
NISE 3140, NISE 3140E, NISE 3140P2, NISE 3140P2E User Manual
SATA2 Power Connector
Connector size: 4-pin Wafer, 2.54mm-M-180
Connector location: CN15
1
4
Pin Definition
1 +12V
2 GND
3 GND
4 VCC5
