Chapter 2: Jumpers and Connectors
NISE 3140, NISE 3140E, NISE 3140P2, NISE 3140P2E User Manual
GPIO Connector
Connector size: 10-pin header, 2x5 (2.0mm -M-180)
Connector location: JP3
1
2
9
10
Pin Definition Pin Definition
1 VCC5 2 GND
3 GPO1 4 GPI1
5 GPO2 6 GPI2
7 GPO3 8 GPI3
9 GPO4 10 GPI4
GPIO LED Connector
Connector size: 2x2 (2.0mm -M-180)
Connector location: JP2
1 2
3 4
Pin Definition
1 GPO_LED0
2 GND
3 GPO_LED1
4 GND
