Nexo GEO S12 Series System Manual

GEO S12 HARDWARE SETUP PROCEDURE
System Manual GEOS12 LS18 Page 59 / 95
Optional GPT-TLB link bar for GPT- XBOW
GPT-XBOWs are delivered with standard link bars which allow both stacked and flown setups. However, these link bars require
perfect alignment of angle setting holes when adding cabinets.
GPT-XBOW standard link bar
To facilitate stacking operation, an optional link bar with oblong holes (GPT-TLB, pair of link bars provided with two 8x20 quick
release pin) is available in the GEO S12 accessory range.
GPT-TLB, GPT- XBOW OPTIONAL link bar
To install GPT-TLB, remove the standard link as well as nut, screw and washers.
When using GPT-XBOW for stacked setups, insert pins in the two circular holes.
REMOVING STANDARD LINK BAR INSERTING PIN - STACKED SETUPS
