System Manual PSR2 Series Page 69 / 109
8.4 PS15R2
8.4.1 System specifications
PS15R2 WITH NEXO TDCONTROLLER SETUP
Frequency Response @-6 dB
47 Hz to 18 kHz
Sensitivity 1W@1m
102 dB SPL Nominal
Peak SPL@1m
133 to 136 dB
HF Dispersion
50° to 100° Horizontal – 55° Vertical Rotatable Horn
Passive Crossover Frequency
1.1 kHz
Nominal Impedance
Active mode : (8 Ω LF + 16 Ω HF) / Passive mode : 8 Ω
Recommended Power
Active mode: (1400 Watts LF + 650 Watts HF) / Passive mode: 1400 Watts
PRODUCT FEATURES
LF Component
1 x 15”x3" long excursion Neodymium 8 Ohms driver
HF Component
1x 2" throat, 3" Titanium diaphragm driver on a low distortion constant directivity
asymmetrical dispersion horn
Height x Width x Depth
675 mm x 434 mm x 368 mm (26.57” x 17.08” x 14.48”)
Weight: Net
28 kg (62 lb)
Connectors
2 x NL4, 4 poles connectors (1+/1- Through / 2+/2- PS15R2 in passive mode,
1+/1- LF, 2+/2- HF in active mode)
Construction
Baltic Birch Plywood & structured black coating
Fittings
2 x Metal recessed handles
Front Finish
Molded dark grey metal grill
Operating temperature range
0°C - 40 °C (32° F - 104° F)
Storage temperature range
-20 °C - 60 °C (-4 ° F - 140° F)
SYSTEM OPERATION
Recommended powering solution
NXAMP4x2mk2 Powered TD controller: 2 x PS15R2 in passive mode per channel
Optional powering solution
NXAMP4x4mk2 Powered TD controller: 4 x PS15R2 in passive mode per channel
NXAMP4x1mk2 Powered TD controller (Bridged): 2 x PS15R2 in passive mode
per channel
DTD Controller + DTDAMP4x1.3 Bridge Stereo: 1 x PS15R2 in passive mode per
channel
