57
Selecting the Wireless Access Option
1. SSID. Type-in the
SSID name or click on
the “Rescan” button to
automatically search for
the available wireless
network connections.
2. Password. Type-in the correct password to join the
wireless network connection selected.
3. IP Address. Select either DHCP or Manually assign
an IP address
a. By selecting DHCP, the host will provide an auto-
matic IP address to connect to the internet
b. By selecting Manual, you have to manually assign
an IP address to connect to the internet
Selecting the Wired Access Option
By selecting the Wired Access option, the Dynamic IP
is selected as the default setting. You can manually
assign your own IP address by clicking on the green
arrow and select the Static IP option.
11.8 Network Services
Windows sharing and network services are available
to access the WIFI Drive
11.8.1. Windows Sharing Services
Data sharing and accessing the Wi-Fi HD product
