Step 1. Unpacking and accessories.
Step 2. Remove protective plastic film.
Step 3. Connect ANT Cable.
After open the gift box, you should check up and find the following items.
- Digital HD-STB
- Universal Remote Control
If you find a missing or broken parts, then ask your supplier or contact the service
center.
Prepare HD-STB and HDTV you want to connect.
Thereareseveralmethodsto Youshouldfindthecorrect
connection method for your HDTV. Please Video Connection Diagram.
Prepare HDTV or Audio equipment you want to connect.
If you are using HDMI connection, you do not need audio connection.
There are four different connection methods for Audio connection. For general TV
analog audio connection, it has Audio L/R.
For digital audio connection, you should prepare Optical Audio cable for optical audio
connection with Home Theater Equipment.
If your Home Theater Equipment system has coaxial digital input, you can use well-
shielded RCA cable for coaxial audio connection.
Plug the Power Cord to wall AC outlet. The power source is AC 180-250V~, 50/60Hz.
This unit is designed for continuous operation. Switching it off does not disconnect it
from the AC outlet. To disconnect this HD-STB from AC outlet, you have to unplug the
HD-STB.
- 2 Batteries AAA (LR03) size
-UserManual
- SD A/V Cable (Yellow/White/Red) & HD Video Cable (Green/Blue/Red)
Remove protective plastic film from HD-STB top cover.
Connect external ANT cable to ANT IN.
Connect another ANT cable between LOOP OUT of HD-STB and ANT IN of TV for
analog reception.
Step 4. Connecting the Video.
Step 5. Connecting the Audio.
Step 6. Connecting the Power.
Step 7. Display Mode Setup.
connecting the video.
refertothe
The default display mode is native 1080i. If you need change the display mode, press
the " DISPLAY MODE" button at the front panel. Press UP or DOWN button at the front
panel to select desired display mode. Press "OK" button to confirmed display mode
Change.
7
Getting Started
*The contents and specifications in this manual are subject to change without prior notice.
Step 8. Install Remote Control battery and Universal Code
setting.
Step 9. Check up the On Screen Display.
Install Remote Control battery. The battery has polarity so when insert the batteries,
make sure the + a nd - t erminals are oriented correctly. The mode selection buttons
areTV,VCR,DVDandSTB.Youcanchangethecodeof otherCEcomponent with
this mode button. For more detailed information, please refer to the Remote Control
Universal Code Setting section.
For verify correct setting of Display Mode, you should check up the OSD from HDTV s
display screen.
Turn on the HD-STB and HDTV. Press Menu button on the remote control, you should
checkuptheOSDforverifyA/Vconnection.If youcannotfindanyOSDinyourTV
display, please check up again the Display Mode Setting and A/V connection.
Step 10. Automatic Channel Search and Channel Change.
Please set the time Zone and perform the Automatic Channel Search to find possible
channels.Pleasemakesure,youshouldwaituntilfullysearched.Normally,itwilltake
several minutes.
If you setting up the favourite channel using Favourite Setup in the menu system, you
can change the channel using "CH+" or "CH-" between selected favourite channels.
Pleasemakesureinfavoritechannelmode,thechannelchangeoperationisbasedon
Favourite Setting in the internal memory. If you unmark the channel in the favourite
list, you cannot access the channel using "CH+" or "CH-" button. At that time, please
perform the Favourite Setup and mark the Channel in the favourite list.
