Nibe ACVM 270 User Manual

List of components
Pipe connections
Climate system supplyXL1
Climate system returnXL2
Cold waterXL3
Hot waterXL4
Docking inXL8
Docking outXL9
Liquid line refrigerantXL13
Gas line refrigerantXL14
Connection safety valve, manometerXL15
Valves etc.
Heat exchangerEP2
Circulation pump, climate systemGP1
Particle filterHQ1
Drying filterHZ2
Valve, draining/filling climate systemQM1
Venting valveQM20
Venting valveQM24
Venting valveQM60
Actuator, shuttle valve, hot waterQM30
Actuator reversing valve, climate system supplyQM31
Shut off valve, climate system returnQM32
Actuator, mixing valveQN11
Electrical components
Terminal block, incoming mains supplyX1
Terminal block, outgoing supply and communicationX2
Terminal block, external additionX3
SwitchSF1
Miniature circuit breaker, control systemFA1
Miniature circuit breaker, outdoor unitFA2
Immersion heaterEB1
Display unitAA4
Relay cardAA6
CPU cardAA21
EBV cardAA22
R24 Setting, fuse size
R25 Setting, max power, electric additional heat
R26 Setting, max boiler temperature
Communication boardAA23
ContactorQA1
ContactorQA2
ContactorQA3
ContactorQA10
Sensor, thermostats
Pressure sensor, high pressureBP4
Temperature sensor, HW chargingBT6
Temperature sensor, condenser outBT12
Temperature sensor, fluid pipeBT15
Temperature sensor, immersion heaterBT19
Temperature sensor, dockingBT24
Thermostat, standby modeBT30
Temperature limiterFD1
Miscellaneous
Cable glandUB1
Cable glandUB2
Cable glandUB4
Rating platePF1
Serial number platePF3
Sign, pipe connectionsPF4
Component location according to IEC 62400.
NIBE™ SPLIT ACVM 27074
Miscellaneous
Component positions
