General
FIGHTER 200P
For Home Owners
2
In order to get the ultimate benefit from your heat pump FIGHTER 200P you should read
through the For Home Owners section in this Installation and Maintenance Instruction.
FIGHTER 200P is an exhaust air heat pump. This means it utilises energy in ventilation air
and uses this energy for hot water and heating the house. A microprocessor ensures that
the heat pump always works efficiently.
For the installation engineer: Please, hand over to the home owner this manual after
finalised installation.
To be filled in when the heat pump has been installed
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Rights to make any design or technical modifications are reserved.
Manufacter:
NIBE AB
Box 14
Järnvägsgatan 40
285 21 MARKARYD
SWEDEN
Maxiumum water
supply pressure
16 bar
Immersion heater R50 / 3000W /
230 V
Operating pressure, tap
water
6 bar
Expansion vessel, tap
water, charge pressure
3,5 bar
Expansion vessel, hea-
ting water,
charge pressure
0,5 bar
Pressure reduction valve,
setting
3,5 bar
Volume, water heater 170 litres
Mass, unit, filled with
water
435 kg
Maximum primary wor-
king
pressure (heating side)
2,5 bar
Set opening pressure of
temperature and pres-
sure valve
7 bar
Set opening pressure
relief valve
6 bar
Set opening, temerature
limiter,
immersion heater
88 °C
Set opening, temerature
limiter,
compressor
88 °C
Heating up time from
15 °C to stop tempera-
ture for compressor
7 h 8 min
Re-heating time, 70 % of
total volume (only com-
pressor working)
4 h 50 min
The serial number (103), should always be stated with all
correspondence with NIBE.
______________
Installation date
Installer
Pre-pressure in the expansion vessel (0.5 bar on delivery)
Circulation pump setting
Flow water maximum temperature
Selected fan curve, normal speed (Knob “Exhaust air” B)
l/s m
3
/h
Selected fan curve, reduced speed (Knob “Exhaust air” A)
l/s m
3
/h
Date___________ Signed_________________________________
