54 NIBE VVM 300
Miscellaneous
Technical specifications
F2016-6 Part no. 064 081
F2016-8 Part no. 064 082
F2016-11 Part no. 064 083
Lower cabinet
Height: 375 mm.
Part no. 089 196
Base extension
Height: 125 mm.
Part no. 089 195
Accessories
Extra shunt ESV 20
Part no. 089 317
LEK
LEK
Over cabinet
LEK
LEK
Height: 245 mm. Part no 089 424
Height: 345 mm. Part no 089 426
Height: 385-535 mm. Part no 089 428
LEK
LEK
LEK
GRUNDFOS
Type UPS 25 - 60 130 P/N:59526447
230V-
H
E
JSA
N
PC;0017NIB
DK
50Hz
IP 44
TF 110
Class H
Max. 10bar
2.5uF
450.20
65
0.30
900.40
1m(A) P,(W)
Room thermostat RT 10
Part no. 418 366
POOL 20
Part no. 064 006
LEK
10
15
20
25
30
¯C
Room unit RE 10
Part no. 067 004
LEK
