TABLE 6 - Second level functions (8 possible parameter values)
Entry LED
Parameter
LED (level) Value Description
L5
Strength of engines
(amperometric
sensitivity)
L1 Level 1 - Minimum strength
Adjusts the strength of both engines.
The control unit has a system for measuring the current
consumed by the two motors that is used to detect the
mechanical stops and any eventual obstacles during
movement of the gate. Since the current consumed de-
pends on variable conditions (gate weight, various types
of friction, gusts of wind, variations in voltage, etc.) there
is the option to change the intervention threshold. 8 lev-
els are provided: level 1 is the most sensitive (minimum
strength), level 8 the least sensitive (maximum strength).
Increasing the value of the degree of amperometric sensi-
tivity increases the deceleration speed in the manoeuvre's
closing stage.
WARNING! – The suitably adjusted "amperometric"
function (together with other essential devices) can
be useful for complying with European standards EN
12453 and EN 12445, which require the use of proce-
dures and devices to limit strengths and dangers in
the movement of automatic doors and gates.
L2 Level 2 - ...
L3 Level 3 - ...
L4 Level 4 - ...
L5 Level5-...
L6 Level 6 - ...
L7 Level 7 - ...
L8 Level 8 - Maximum strength
L6
Door delay
L1 0%
Adjusts the delay in the starting of the lower door's motor;
can be programmed as a percentage of the working time.
L2 5%
L3
10%
L4
15%
L5 20%
L6 30%
L7 40%
L8 50%
L7
Maintenance notice
L1 500
Adjusts the number of manoeuvres after which to signal
the automation's maintenance request (see paragraph
"4.3 - Maintenance notice")
L2 1000
L3 1500
L4 2500
L5 5000
L6 10000
L7 15000
L8 20000
L8
Faults list
L1
Outcome 1
a
manoeuvre (the most
recent)
Allows the type of fault that has occurred in the last 8 ma-
noeuvres to be checked (see paragraph "4.4 - Historic
faults log")
L2 Outcome 2
a
manoeuvre
L3 Outcome 3
a
manoeuvre
L4 Outcome 4
a
manoeuvre
L5 Outcome5
a
manoeuvre
L6 Outcome 6
a
manoeuvre
L7 Outcome 7
a
manoeuvre
L8 Outcome 8
a
manoeuvre
