12 – English

WARNINGS:•Alltechnicalcharacteristicsstatedrefertoanambienttemperatureof20°C(±5°C).•NiceS.p.areservestherighttomodifytheproductatany

timee, while maintaining the same functionalities and intended use.

Mains power supply MC424L Control units: 230 V

~±10%50÷60Hz;fuse: 1A type T

MC424L/V1 Control units: 120 V~±10%50÷60Hz;fuse: 2A type T

Max absorbed power 170 W

Emergency power supply for PS124 buffer batteries

and for Solemyo solar kit

Maximum motor current: 3A (with a “level 6” current sensitivity cut in)

Service power output 24 V

200 mA maximum current (the voltage can vary from 16 to 33 V )

Phototest Output 24 V

100 mA maximum current (the voltage can vary from 16 to 33 V )

Flashing lamp output forashinglamp24V

,maximumpower25W(thevoltagecanvaryfrom16to33V )

Gate open indicator output for indicator lamps at 24 V

maximumpower5W(thevoltagecanvaryfrom16to33V )

or electric locks 12 V~25W

STOP Input  forNCcontactsorconstantresistance8,2KΩ+/-25%

Working time automatic detection

Pause time programmable at 5,15,30,45,60,80,120,180 seconds

Discharge time programmable to 0.2, 0.4, 0.6, 0.8, 1.0, 1.2, 1.4 seconds

Leaf delay in open cycle programmable at 0,5,10,15,20,30,40,50% of working time

Leaf delay in close cycle automatic detection

1st motor output for Wingo(WG2024,WG3524,WG4024,WG5024),Too(TOO3024,TOO4524),S-fab(XME2024)

2nd motor output for Wingo(WG2024,WG3524,WG4024,WG5024),Too(TOO3024,TOO4524),S-fab(XME2024)

Max. cable length power supply 30 m

Solemyo solar power kit 3 m

motors 10 m

other inputs/outputs 30 m

ashinglight 10m

OGI 30 m

electric lock 10 m

aerial 20 m

(recommended less than 3 m)

Radio receiver “SM” type coupling for receivers SMXI, SMXIS, OXI (Mode I and Mode II)

Temperatura di esercizio from-20to55°C

Protection rating IP54withenclosureintact

Dimensions (mm) 310 x 232 x H 122

Weight (kg) 4,1

TECHNICAL CHARACTERISTICS OF THE PRODUCT

EU Declaration of Conformity

and declaration of incorporation of “partly completed machinery”

Note - The content of this declaration corresponds to that specied in the ofcial document deposited at the Nice S.p.A. headquarters and, in particular, to the latest revised edition

available prior to the publishing of this manual. The text herein has been re-edited for editorial purposes. A copy of the original declaration can be requested from Nice S.p.A. (TV) I

Number: 296/MC424 Revision: 5  Language: EN

Manufacturer’s Name: Nice s.p.a.

Address: Via Pezza Alta 13, Z.I. Rustignè, 31046 Oderzo (TV) Italy

Person authorised to compile

the technical documentation: Nice s.p.a.

Type of product: Comand central a 2 motor 24V dc

Model / Type: MC424, MC424L

Accessories: Radio receiver OXI

TheundersignedRobertoGriffa,intheroleofChiefExecutiveOfcer,declaresunderhissoleresponsibilitythattheproductdescribedabovecomplieswith

the provisions laid down in the following directives:

•Directive2014/30/EU(EMC),inaccordancewiththefollowingharmonisedstandards:EN61000-6-2:2005,EN61000-6-3:2007+A1:2011

The product also complies with the following directives according to the requirements envisaged for “partly completed machinery” (Annex II, part 1, section B):

Directive2006/42/ECoftheEUROPEANPARLIAMENTANDCOUNCILof17May2006relatedtomachineryandamendingtheDirective95/16/EC(recast).

• It is hereby stated that the relevant technical documentation has been compiled in accordance with annex VII B of Directive 2006/42/EC and that the following essential require-

mentshavebeenfullled:1.1.1-1.1.2-1.1.3-1.2.1-1.2.6-1.5.1-1.5.2-1.5.5-1.5.6-1.5.7-1.5.8-1.5.10-1.5.1.

• The manufacturer undertakes to transmit to the national authorities, in response to a reasoned request, the relevant information on the " partly completed machinery ", while

maintaining full rights to the related intellectual property.

•Shouldthe"partlycompletedmachinery"beputintoserviceinaEuropeancountrywithanofciallanguageotherthanthatusedinthisdeclaration,theimporterisobligedto

arrange for the relative translation to accompany this declaration.

•The“partlycompletedmachinery”mustnotbeuseduntilthenalmachineinwhichitisincorporatedisinturndeclaredascompliant,ifapplicable,withtheprovisionsofdirective

2006/42/EC.

The product also complies with the following standards:

EN60335-1:2012+A11:2014,EN62233:2008,EN60335-2-103:2015

Oderzo,05/09/2017 Ing.RobertoGriffa

(ChiefExecutiveOfcer)
