4.1 Setting 901 – Lock Relay Time
Allowed Values = 0 - 255 Default value = 10
The value for this setting is the time that the Lock relay activates for, in
seconds, when a valid code is used or the REX input is activated.
Note that a value of 0 for this setting will cause the Lock relay to be in
latching mode, making it alternate between open and closed on each
code usage. This will also disable the REX input.
Example: sets the lock relay time to 15 seconds.
4.2 Setting 902 – Lock Relay Mode
Allowed Values = 0 - 1 Default value = 0
Set the Lock relay as NO (Normally Open, Fail Secure) or NC (Normally
Closed, Fail Safe), 0 = NO, 1 = NC.
4.3 Setting 903 – REX Input Mode
Allowed Values = 0 - 3 Default value = 0
Sets how the REX input responds, 0 = NO momentary,
1 = NC momentary, 2 = NO continuous, 3 = NC continuous.
NO setting activates when REX is connected to 0V.
NC setting activates when REX is disconnected from 0V.
Momentary setting starts the Lock relay timing for the Lock relay when
the REX activates, continuing to hold the REX active has no effect and
the REX input will not trigger the Lock relay again until it is released then
activated again.
Continuous setting activates the Lock relay for the entire time the REX
input is active, the Lock relay timing starts when the REX input is released.
4.4 Setting 910 – Auxiliary Mode
Allowed Values = 1 - 12 Default value = 8
This setting determines the function of both the Auxiliary Input and the
Auxiliary Relay. Descriptions of the input and relay functions are
provided after the summary table below.
2 Lock REX Direct Shunt
