Nikon D3300 Reference Manual

84 More on Photography
❚❚ The Electronic Rangefinder
If the lens has a maximum aperture of
f/5.6 or faster, the viewfinder focus
indicator can be used to confirm whether
the subject in the selected focus point is
in focus (the focus point can be selected
from any of the 11 focus points). After
positioning the subject in the selected
focus point, press the shutter-release button halfway and rotate
the lens focus ring until the in-focus indicator (I) is displayed.
Note that with the subjects listed on page 76, the in-focus
indicator may sometimes be displayed when the subject is not in
focus; confirm focus in the viewfinder before shooting.
A
Selecting Manual Focus with the Camera
If the lens supports M/A (autofocus with
manual override) or A/M (autofocus with
manual override/AF priority), manual focus
can also be selected by setting the camera
focus mode to MF (manual focus; 0 74).
Focus can then be adjusted manually,
regardless of the mode selected with the
lens.
A Focal Plane Position
The position of the focal plane is indicated
by the focal plane mark on the camera body.
The distance between the lens mounting
flange and the focal plane is 46.5 mm
(1.83 in.).
Focal plane mark
46.5 mm

Nikon D3300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6000 x 4000 pixels
Still image resolution(s)	4800 x 1080, 1632 x 4800, 9600 x 1080, 1632 x 9600, 4496 x 3000, 2992 x 2000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto
Auto Focus (AF) lock	Yes
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted
ISO sensitivity	100, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Flash off, Flash on
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	PCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.85 x
USB version	2.0
HDMI connector type	Mini
Scene modes	Children, Close-up (macro), Night portrait, Sports, Landscape (scenery)
Image editing	Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Shade
Shooting modes	Scene
Camera playback	Movie, Single image
Self-timer delay	2, 5, 10, 20 s
Languages support	ARA, BUL, CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, FIN, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SER, SWE, THA, TUR, UKR
Camera file system	RAW
Battery type	EL14a
Number of batteries supported	1
Product color	Red
Storage temperature (T-T)	0 - 85 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	98 mm
Width	124 mm
Height	75.5 mm
Weight	410 g
Weight (including battery)	460 g
