Nikon D5000 User Manual

18
X
Attach a Lens
Care should be taken to prevent dust from entering the camera when the lens is
removed.
An AF-S DX NIKKOR 18–55mm f/3.5–5.6G VR lens is used in this manual for
illustrative purposes.
1 Turn the camera off.
2 Remove the rear lens cap and the
camera body cap.
3 Attach the lens.
Keeping the mounting index on the
lens aligned with the mounting index
on the camera body, position the lens
in the camera’s bayonet mount (q).
Being careful not to press the lens-
release button, rotate the lens
counter-clockwise until it clicks into
place (w).
If the lens is equipped with an A-M or
M/A-M switch, select A (autofocus) or
M/A (autofocus with manual priority).
D Autofocus
Autofocus is supported with only AF-S and AF-I lenses, which are equipped with autofocus
motors.
Autofocus is not available with other AF lenses.
Focal length scale
Focal length index
A-M mode switch (see below)
VR (vibration reduction) switch (0 19)
Mounting index
Rear lens cap
Lens cap
Focus ring (0 60, 229)
CPU contacts
(0 194)
Zoom ring

Nikon D5000 Specifications

General

Megapixel	12.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	DX
Image stabilizer	No
Total megapixels	12.9 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	4288 x 2848 pixels
Image sensor size (W x H)	23.6 x 15.8 mm
Still image resolution(s)	4288 x 2848 3216 x 2136 2144 x 1424
Mounting type	Bayonet
Lens mount interface	Nikon F
Video recording	Yes
Video resolutions	320 x 216, 640 x 424, 1280 x 720 pixels
Motion JPEG frame rate	24 fps
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Magnification	0.78 x
Eye relief	17.9 mm
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Food, Night landscape, Night portrait, Party (indoor), Pet, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Trimming
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Zoom
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF, Exif 2.21
Product color	Black
Battery life (CIPA standard)	510 shots
Number of batteries supported	1
Focus adjustment	Auto/Manual
Auto Focus (AF) points	11
Auto focusing (AF) modes	Servo Auto Focus, Single Auto Focus
Flash modes	Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Flash range (tele)	- m
Flash exposure correction	-3EV - +1EV (1/2; 1/3 EV step)
Compatible memory cards	SD, SDHC
Light metering	Centre-weighted, Matrix, Spot
ISO sensitivity	100, 200, 3200, 6400
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure correction	±5EV (1/2; 1/3 EV step)
Audio system	Mono
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
PictBridge	-
USB version	2.0

Weight and Dimensions

Depth	80 mm
Width	127 mm
Height	104 mm
Weight	560 g
