2. PREPARATION
2-1
2
PREPARATION
2-1. Unpacking and Packing the DTM-502
NOTE • Handle gently the DTM-502 to guard against shocks or excessive
vibration.
• Encase the instrument with the battery pack attached.
• When packing the charger Q-75U/E in the plastic carrying case, make
sure the storing position referring to the sticker inside of the case. Be
careful not to pinch the cable of the charger when closing the case
cover.
1) Unpacking
Hold the carrying-handle and take the
instrument out of the case. The instrument
is placed in its carrying case as shown in the
figure.
2) Packing
Set the telescope in the horizontal “face-left”
position and align the storage mark (
) on
the bottom of the face-left keyboard and the
mark (
) on the leveling base clamp knob.
Fasten lightly the clamp knobs and then
replace the instrument in its case.
