3
O/S: 4. +Lin
Input PT (and CD) and press the [ENT] key to
record the point. Height of target is fixed to 0.0000
for the offset point.
= Sxample records in [O/S]
→
[4. +Line by HA] =
SS, 40, 0.0000, 48.3304, 169.20370, 82.02470, 10:52:37
CO, PT1, 0.0000, 48.3020,169.19165, 83.58565
CO, PT2, 0.0000, 48.3155,168.54250, 85.42440
CO, O/S MSR:40 0.0000 169.20370 87.02340
• The calculated point (TGT) is stored as a SS record.
• Measurements to the first and second target (P1 and P2) are stored as comment
records, PT1 and PT2. The last record is of the angle measurement to the ALT
(vertically offset point from the actual target point).
3-75
