SO records
SO: Stakeout shots. Shots recorded in Stakeout functions.
Pressing the [DSP] key switches the display in the following order when the “Store
DB” setting sets to “RAW+XYZ”..
3
MENU: 4. Data
1st screen
HA:
VA:
SD:
PT:
HT:
2nd screen
X:
Y:
Z:
PT:
CD
:
3ｒd screen
dX:
dY:
dZ:
PT:
CD:
• dX/dY/dZ is difference in coordinates to its planned (designed) position. It will be
downloaded as a comment record in Nikon RAW format.
CO records
A comment added to the job from the system.
For example, when you change the Stn-Z by the Remote Benchmark function, or
the horizontal angle is reset by the BSCheck function, the system records what
you have done in the field.
A sample comment record from the Remote
Benchmark function is shown right.
Temperature, Pressure and Prism Constant record
(SY record) is also stored when you complete a
station setup.
3-106
