Individual Operations
3
Item Title Operating sections
3.1 Power ON/OFF Power switch, battery, AC adapter
3.2 Brightness Adjustment Brightness control knob, preset switch, ND filter, color
compensating filter
3.3 Optical Path Switching Optical path switching knob
3.4 Vertical Stage Motions Coarse/fine adjustment knobs, coarse torque adjustment
ring, refocusing lever
3.5 Lateral Stage Motions X knob, Y knob, XY knob torque adjustment screws
3.6 Diopter Adjustment Diopter adjustment rings
3.7 Interpupillary Adjustment Eyepiece sleeve
3.8 Adjusting Observation Position Ergonomic binocular tube
3.9 Adjusting Condenser Position Condenser focus knob, condenser centering screws
3.10 Aperture Diaphragm Adjustment Condenser aperture diaphragm, objective
3.11 Selection of Condenser Condenser
3.12 Field Diaphragm Adjustment Field diaphragm knob
3.13 Oil Immersion Operation Oil immersion objectives, oil immersion condensers
3.14 Water Immersion Operation Water immersion objectives, water immersion condensers
3.15 Operation of Cytodiagnostic Unit Cytodiagnostic unit, hand switch
3.16 Fluorescence observation Fluorescence attachment
3.17 Fluorescent Filter Selection Filter cube
3.18 Image Capture Camera
