23
Step 9
The drop catcher is mounted in the VPM module.
a. Drop catcher
b. Evaporator
c. Condensate tray
d. EC-fan
a
a
c
b
d
Step 10
If the unit comes with a discharge module, repeat the
steps for the discharge module.
