CAT-5 Cable
USER INTERFACE CONTROLS
iREMOTE
®
TWO WAY WIRELESS RF SYSTEM CONTROL REMOTE WITH LCD DISPLAY
Display – Backlit
LCD displays system
information from
Modules and functions
associated with “Soft
Keys”
PREV/NEXT
2 backlit buttons move to
Next or Previous/Track
or Station
Alphanumeric Keys
Provide direct access
tuning, numeric selection
of track and alphabetic
search for iPod
MUTE
Backlit button mutes/
un-mutes audio output
to zone
Niles System Settings
Provides access to system
settings: audio (bass,
treble, balance), sleep
timer, alarm clock, etc.
Charging Base
Battery Indicator
12V DC
Power Supply
Soft Keys
3 backlit buttons
that change function
depending upon the
source selected
Cursor Keys
and Select Key
5 backlit buttons provide
navigation of menus,
playlists and favorites
Master Keys
8 backlit buttons provide
“One Touch to Music”
OFF
Backlit button turns zone
or system off
VOL+/VOL–
2 backlit buttons adjust
volume up or down
The IntelliControl
®
ICS iRemote is a two-way RF (Radio
Frequency) hand-held remote control user interface.
Eight backlit Master Keys provide Niles exclu-
sive “One Touch to Music,” which turns the
system on, selects a source and starts the music.
Additional backlit Hard Keys and Soft Keys
provide complete source and system control.
The High Resolution LCD displays metadata, setup menus
and important system information from the Niles Modules.
The iRemote includes a Master Charging Base that
recharges the battery and communicates with an
IntelliControl ICS Modular MultiZone Receiver to
provide system status updates from any zone.
INTELLICONTROL
®
ICS PRODUCTS OVERVIEW
