BASIC SIX ZONE INTELLICONTROL
®
ICS SYSTEM
EXAMPLES OF INTELLICONTROL
®
ICS SYSTEM CONFIGURATIONS
COMMUNICATION
& CONTROL SWITCH
VIDEO
OUT
CASCADE AUDIO
OUT
SIRIUS
ANTENNA
Speakers Speakers
Speakers
FM
ANTENNA
AM
ANTENNA
XM
ANTENNA
FM
ANT
TM-AM/FM
AM
ANT
L
R
CASCADE AUDIO
OUT
Niles Audio Corporation Miami Florida, USA
Speakers
16/4
Speaker
Wire
CAT-5
Cable
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5
Speakers
ZONE 6
Speakers
To Left Speaker
To Right Speaker
L
AUDIO OUT
DIGITAL AUDIO OUT
R
OPTICAL COAXIAL
Satellite Receiver DVD/CD Player
IR Flasher
CS-12V
to 3-30V SYNC IN
To Unswitched
Outlet
iPod
Figure 7.
