TECHNICAL DATA
General SC350
Min/max machine length at the handlebar 810/1,270 mm
Machine width 470 mm
Min/max machine height with adjustable handlebar 550/1,000 mm
Weight without battery and with empty tanks 42 kg
Maximum weight with battery and full tanks (GVW) 80 kg
Cleaning width 370 mm
Battery compartment size 350x175x240 mm
Diameter of wheels on xed axle 200 mm
Brush/pad diameter 370 mm
Rear wheel pressure on the oor (*) 0.5 N/mm
2
Brush/pad pressure on the oor 18 kg
Brush/pad pressure with full tank 27 kg
Performance SC350
Vacuuming 710 mmH
2
O
Min/max solution ow
SET1: 0.25 litres/min
SET2: 0.5 litres/min
Brush/pad-holder motor speed 140 rpm
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 65 dB(A) ± 3dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) < 2.5 m/s
2
Vacuum system motor power 200 W
Brush/pad motor power 240 W
Maximum gradient when working 2%
Battery voltage 12 V
Standard battery 12V 55AhC20 AGM Spiralcell
Standard battery autonomy 1 hour
Solution tank capacity 11 litres
Recovery tank capacity 11 litres
Machines have been tested under the following conditions:(*)
Maximum battery size•
Maximum brush and squeegee size•
Full clean water tank•
Optional components installed•
Weight on wheels checked•
Print on the oor checked on cement for each single wheel•
Result expressed as maximum value for rear wheels•
