ENGLISH
INSTRUCTIONS FOR USE
8
9099122000(1)2011-01 SC350
TECHNICAL DATA
General SC350
Min/max machine length at the handlebar 31.9 in / 50 in (810 mm / 1,270 mm)
Machine width 18.5 in (470 mm)
Min/max machine height with adjustable handlebar 21.6/39.4 in (550/1000 mm)
Weight without battery and with empty tanks 92.6 lb (42 kg)
Maximum weight with battery and full tanks (GVW) 176 lb (80 kg)
Cleaning width 14.5 in (370 mm)
Battery compartment size 17.8x6.9x9.4 in (350x175x240 mm)
Diameter of wheels on xed axle 7.9 in (200 mm)
Brush/pad diameter 14.5 in (370 mm)
Rear wheel pressure on the oor 72.5 psi (0.5 N/mm
2
)
Brush/pad pressure on the oor 39.6 lb (18 Kg)
Brush/pad pressure with full tank 59.5 lb (27 Kg)
Performance SC350
Vacuuming 0.0069 MPa (710 mmH
2
O)
Min/max solution ow
One drop: 0.066 gpm (0.25 liters/min)
Two drops: 0.13 gpm (0.5 liters/min)
Brush/pad-holder motor speed 140 rpm
Sound pressure level at workstation (ISO 11201, ISO 4871, EN 60335-2-72) (LpA) 65 dB(A) ± 3dB(A)
Machine sound pressure level (ISO 3744, ISO 4871, EN 60335-2-72) (LwA) 84 dB(A)
Vibration level at the operator’s arms (ISO 5349-1, EN 60335-2-72) 98.4 in/s
2
(< 2.5 m/s
2
)
Vacuum system motor power 0.27 HP (200 W)
Brush/pad motor power 0.32 HP (240 W)
Maximum gradient when working 1.14° (2%)
Battery voltage 12 V
Standard battery 12V 85AhC5 AGM
Standard battery autonomy 2 hour
Solution tank capacity 2.9 USgal (11 liters)
Recovery tank capacity 2.9 USgal (11 liters)
