ENGLISH
INSTRUCTIONS FOR USE
10
9099122000(1)2011-01 SC350
USE
WARNING!
On some points of the machine there are some adhesive plates indicating:
DANGER –
WARNING –
CAUTION –
CONSULTATION –
While reading this Manual, the operator must pay particular attention to the symbols shown on the plates.
Do not cover these plates for any reason and immediately replace them if damaged.
BATTERY CHECK/SETTING ON A NEW MACHINE
The machine is supplied with 1 GEL/AGM 12 V battery already installed on the machine.
Open the cover (4) and check that the battery is connected to the machine with the connector (7).1.
Start the machine (see Machine Start and Stop paragraph). If the green warning light (38) turns on, the batteries are ready to 2.
be used.
If the yellow or red warning light turns on, the battery must be charged (see the procedure in Maintenance chapter).3.
BEFORE MACHINE START-UP
Brush/pad-holder installation/removal
WARNING!
If the machine is not perfectly assembled it can cause damages to people and properties. Always check that all
components are assembled before starting the machine. Carefully inspect the machine before using it.
NOTE
Install either the brush (A, Fig. 1) or the pad-holder (B and C) according to the type of fl oor to be cleaned.
Lift the brush/pad-holder deck (12) by prying the handlebar (1).1.
Place the brush (A, Fig. 1) or the pad-holder (B and C) under the deck.2.
Lower the deck (12) by using the handlebar (1).3.
Turn the knob (32) on one of the indicated programs.4.
Press the enabling push-button (39) together with the brush levers (40) to engage the brush/pad-holder.5.
To remove the brush/pad-holder, perform the following procedures.
Switch off the machine by turning the knob (32) to “0”.6.
Slightly lift the machine deck by prying the handlebar (1), then manually release the brush/pad-holder from the hub, by turning 7.
it abruptly in its normal rotation direction (D, Fig. 1).
Front
A
B
C
DD
Figure 1
P100407
