Recovery System 34Service Manual – SC351
Vacuum System Gasket Cleaning
Note: The gaskets (L) and (M)
create vacuum in the
system that is necessary
for vacuuming the recovery
water.
1. Drive the machine on a level oor.
2. Check that the function selection knob is turned
to “0” and disconnect the battery connector.
3. Open the cover (A) and check the vacuum
system motor gasket (L) for integrity.
4. If necessary replace the gasket by removing it
from its housing.
5. Remove the recovery tank (C).
6. Check the recovery water duct gasket (M) for
integrity. If necessary, replace the gasket.
7. Clean with care and reinstall.
A
L
M
C
P100790
