Squeegee System 57Service Manual – SC351
Maintenance and Adjustments
Squeegee Cleaning
Note: The squeegee must be clean
and its blades must be in
good conditions in order to
get a good drying.
Caution! It is advisable to wear
protective gloves when
cleaning the squeegee
because there may be
sharp debris.
1. Drive the machine on a level oor.
2. Check that the function selection knob is turned
to “0” and disconnect the battery connector.
3. Fully turn the brush/pad-holder deck counter-
clockwise.
4. Disconnect the vacuum hose (A) from the
squeegee.
5. Disengage the squeegee (B) from the deck.
6. Wash and clean the squeegee. In particular,
clean the compartments (C) and the vacuum
hole (D).
7. Check the front blade (F) and the rear blade
(G) for integrity, cuts and tears; if necessary
replace them (see the procedure in the following
paragraph).
8. Assemble the components in the reverse order of
disassembly.
A
B
C
D
E
F
C
P100810
