Nilfisk-Advance SC351 Service Manual

Control System 18Service Manual – SC351
Removal and Installation
LED Electronic Board (EB1) Disassembly/Assembly
Disassembly
1. Drive the machine on a level oor. Make sure
that the machine cannot move independently.
2. Turn the machine program selection knob to “0”.
3. Disconnect the battery connector.
4. On the lower side of the handlebar with the
control panel, unscrew the screws (A).
5. Lower the upper side (B) of the handlebar with
the control panel.
6. Disconnect the connector (C) of the LED
electronic board (D). Remove the screws (E) and
remove the LED electronic board (D).
7. If necessary, disconnect the connector (F) and
remove the solution ow push-button (G) by
disengaging the inner tabs (H).
A
B
A
A
A
C
F
E
D
E
H
G
P100778
