130Service Manual – SC401, SCRUBTEC 344 30 - Solution System
Maintenance and Adjustments
Cleaning the Water Tank and Filter
1. Drive the machine on a level oor.
2. If equipped remove the ignition key, then disconnect the red battery connector.
3. Drain the water tank with the level hose. Then, rinse the tank with clean water.
4. Close the detergent solution tap (A). The tap (A) is closed when it is in position (B).
5. Remove the transparent cover (C) and the gasket (D), then remove the lter strainer (E). Wash and
rinse them, then ret them carefully onto the lter support (F).
6. Open the valve (A).
Figure 7:
A
B
F
D
E
C
To Next Page
