85Service Manual – SC401, SCRUBTEC 344
14 - Wheel System, Non-Traction
Functional Description
The machine wheel system without drive system consists of front wheels and a pair of pivoting rear wheels.
The front wheel system is the main machine support and pivot of the lifting and lowering brush deck
mechanism.
Component Locations
Figure 1:
Pivoting rear wheels
Front wheels
