Nilfisk-Advance SC401 Series User Manual

150Service Manual – SC401, SCRUBTEC 344 34 - Scrub System, Disc
Specications
Description / Model SC401, SCRUBTEC 344 / BATTERY
Cleaning width 17 in (430 mm)
Brush/pad diameter 17 in (430 mm)
Brush pressure 55 lb (25 kg)
Brush deck right/left o󰀨set 65 / 15 mm (2.5 / 0.6 in)
Brush distance from the oor (when lifted) 1.6 in (40 mm)
Brush motor power 0,6 hp (450 W)
Brush rotation speed 140 rpm
Protection class IP 20
Insulation class F
Description / Model SC401, SCRUBTEC 344 / CORD
Cleaning width 17 in (430 mm)
Brush/pad diameter 17 in (430 mm)
Brush pressure 66 lb (30 kg)
Brush deck right/left o󰀨set 65 / 15 mm (2.5 / 0.6 in)
Brush distance from the oor (when lifted) 1.6 in (40 mm)
Brush motor power 1 hp (750 W)
Brush rotation speed 170 rpm
Protection class IP 55
Insulation class F
